Trusted company that deals in quality-made products
Vibrating Screen Machine
750000.00 INR/Piece
Product Details:
- Motor Power 1.5 HP
- Surface Powder Coated
- Product Type Vibrating Screen Machine
- General Use Industrial screening and separation
- Material Galvanized Iron
- Type Circular Vibrating Screen
- Capacity 150 T/hr
- Click to view more
X
Vibrating Screen Machine Price And Quantity
- 750000.00 INR/Piece
- 1 Piece
Vibrating Screen Machine Product Specifications
- Vibrating Screen Machine
- Circular Vibrating Screen
- Yellow
- 1.5 HP
- Yes
- Powder Coated
- Air Cooled
- Industrial screening and separation
- Vibration Separation
- 1200 mm x 800 mm x 950 mm
- 150 T/hr
- Approx. 320 kg
- Galvanized Iron
- No
- Manual/Panel Control
Vibrating Screen Machine Trade Information
- 1 Piece Per Month
- 30 Days
- Australia, South America, Western Europe, Middle East, Central America, Asia, Eastern Europe, North America, Africa
- All India
- crisil certified , ISO 2008
Product Description
We have gained remarkable position in market as one of the leading manufacturers, supplier and exporters of Vibrating Screening Machine. These machines are highly demanded around the globe for their wider applicability in chemical, metallurgy, mining, food, pharmaceutical and paper industries. Offered machines performs the task of De-dusting, De-watering, over/under size removal and surface finishing. Valued clients can avail these machines from us at market leading prices. Moreover, Vibrating Screening Machine can be availed in customized as well as standard forms.We are one of the trustworthy organizations, engaged in manufacturing and supplying Vibrator Screen Of Stonecrusher.
Construction and Working-
The machine is in circular shape fitted with specially designed vibratory motor at the centre. The machine has interchangeable spacer frame with discharge spout and steardy mesh frame with suitable wire mesh. The whole assembly is fitted by special clamps. The screening assembly consisting of two sets of screen is mounted on a set of annularly located springs, effectively isolating the base from vibrating Assembly.
The double eccentric weight provided on the shaft of the motor create three dimensional vibrations which causes the material falling on the screen move at specific speed in a straight to spiral direction giving controlled and effective screening.Due to adjustability of eccentric weights and relative angle between them, it is possible to make the material movement in desired path to achieve desired retention time for effective screening. During the process the particles smaller than mesh aperture falls through the mesh and oversize material gets discharged from outlet spout. Similar process is repeated on the next mesh in case of multiple deck screening.
Vibratory Screen 18X06
- 6 Deck , Power 30 HP , Screen Sail ms Plate , Body 8-10- mm Plate
- Top 3 Screen 10 mm Plate Middel 2 Screen 8 mm plate,Last screen
- For Dust 4 mm Plate.
- Maintenance Platform.
Product details
|
Minimum Order Quantity |
1 Piece |
|
Plate Thickness |
8-10 mm |
|
Material |
Galvanized Iron |
|
Motor Power |
30 HP |
|
Capacity |
150 TPH |
|
Brand |
VE |
|
Transmission Structure |
Resonance Screen |
|
Usage/Application |
Industrial |
